Oat Flake Processing Line
- Capacity: Oat flake
- Production: 20--300TPD
High-efficiency oat flake production line for processing rolled oats. Includes cleaning, steaming, flaking, drying, and packaging. Custom capacities available.
The oat flake processing line is a fully integrated solution for producing rolled oats from raw oat kernels. This production system includes stages such as grain cleaning, dehulling, steam conditioning, flaking, drying, and packaging. Designed for industrial food production, it supports applications ranging from breakfast cereals to instant oat products.
VOSON’s oat flake processing line is an industrial-grade solution for producing high-quality rolled oats. It is widely used in breakfast cereal production, instant oat products, and healthy food applications. It is customizable to meet various capacity requirements, from small-scale pilot plants to high-throughput cereal processing factories.
Complete Oat Flake Production Process Workflow
1、Grain Cleaning System
Vibratory screens, destoners, and magnetic separators remove impurities like dust, stones, and metal fragments from the raw oats.
2、Oat Dehulling Section (optional)
For raw oats with husks, a dehulling machine efficiently separates hulls from groats with minimal kernel breakage.
3、Groat Grading and Sorting
Particle classifiers ensure consistent groat size, preparing them for uniform steaming and flaking.
4、Steam Conditioning Unit
A continuous or batch-type steam conditioner softens oat groats, optimizing flaking performance and flake texture.
5、Roller Flaking System
Precision rollers compress steamed groats into flakes of controlled thickness, typically 0.5–1.2 mm. Surface finish is smooth and consistent.
6、Drying & Cooling Section
Flakes are dried to the desired moisture content and cooled to ensure product stability and prevent condensation.
7、Oat Flake Packaging Machine
Finished flakes are sieved, weighed, and packed into bags, boxes, or bulk containers according to market requirements.
Technical Specifications of Oat Flake Flaking Line
| Model | Capacity (t/day) | Roller Size (mm) | Power (kW) | Flake Thickness (mm) | Dimensions (mm) |
|---|---|---|---|---|---|
| VSFLK-6060F | 30–40 | 600×600 | 15×2 | 0.5–1.2 | 1600×2100×1650 |
| VSFLK-6100F | 60–80 | 600×1000 | 22×2 | 0.5–1.2 | 2000×2100×1650 |
| VSFLK-6125F | 100–120 | 600×1250 | 30×2 | 0.5–1.2 | 2300×2100×1650 |
| VSFLK-6150F | 150–180 | 600×1500 | 37×2 | 0.5–1.2 | 2600×2200×1750 |
Key Features of the Oat Flake Production Line
- Full stainless steel options for food safety compliance
- Compact layout suitable for plant upgrades or new facilities
- Modular design supports future automation expansion
- Low energy consumption with high yield
- Accurate flake thickness control (±0.05 mm)
- Easy maintenance and wear-resistant rollers
- Remote monitoring available (optional)
Oat Flake Line – Frequently Asked Questions (FAQ)
Q: Can the oat flake line process other grains like wheat or barley?
A: Yes. With minor adjustments, it can process barley, wheat, millet, sorghum, and buckwheat into flakes.
Q: What is the typical lead time for a 60–80 T/D line?
A: Production and delivery typically take 45–60 days depending on custom configurations.
Q: Is installation and training available internationally?
A: Yes. On-site installation and operator training can be arranged worldwide. Remote commissioning support is also available.
Q: Can we integrate this with a packaging system?
A: Yes. We offer optional automated weighing and packaging lines compatible with this system.
VOSON is a leading manufacturer of grain processing machinery with a global footprint in over 20 countries. Our engineering team provides customized turnkey solutions for oat flake lines, dehulling systems, flour mills, and cereal plants.
